New - 2012
Serial No. 1093842
Power On Time - 3772 Hours
Cycle Start Time - 1580 Hours
Feed Cutting Time - 1371 Hours

SPECIFICATIONS:
Table Size............40" x 14"
Travels:
- X-Axis............20"
- Y-Axis............16"
- Z-Axis............14"
Rapid Feedrate XYZ - Maximum............1200 IPM
Cutting Feedrate - Maximum............833 IPM
Spindle:
- Nose to Table............4" - 18"
- Horsepower............15 HP
- Speed............10,000 RPM
- Taper............CT 40
ATC............24 Tools
Tool:
- Tool Weight - Maximum............12 Lbs.
- Tool Diameter - Maximum............3.5"
Change Times:
- Tool to Tool............3.6 Sec.
- Chip to Chip............5.0 Sec.
Coolant Capacity............40 Gallons
Dimensions - Approximate...........91"L X 88"W X 100"H
Weight - Approximate............5,100 Lbs.

EQUIPPED WITH:
Haas Intuitive Programming
WIPS - Renishaw OTS Optical Tool Setter, OPM40-2 Optical Machine Probe, and OMI-2 Optical Machine Interface
20 HP Vector drive
Ethernet Interface
750MB of Memory
Hi-Speed Machining
Rigid Tapping
Programmable Coolant
Chip Auger
4th-Axis Ready
Misc. CAT 40 Tooling
Work Light
Air Blow Off Gun
Lubrication System

*Preliminary specifications, pending confirmation.

This machine is listed for sale by Liberty Machinery Company located in Lincolnshire, Illinois
