Year Built - 2008

SPECIFICATIONS:
Table:
- Size............62.5" x 30"
- Capacity............4,120 Lbs.
- T-Slots............5 x 0.709" x 3.75"
Floor to Table Surface............36"
Spindle Nose to Table............5.5" - 35.5"
Travels:
- X............60"
- Y............30"
- Z............30"
Cutting Feed Rate (X/Y/Z)............0 - 400 ipm
Rapid Traverse Rate (X/Y/Z)............400 ipm
Spindle:
- Speed............10,000 RPM
- Taper............CAT 40
- Motor Power............22.5 HP
Automatic Tool Changer Positions............24
Tool Diameter - Maximum............3" (6" without adjacent tools)
Tool Length - Maximum............15"
Tool Weight - Maximum............16.3 Lbs.
Ball Screw Diameter............1.73" (X/Y), 1.49" (Z)
Electrics............240V
Dimensions - Approximate............189"L x 120"W x 134"H
Weight - Approximate............17,000 Lbs

EQUIPPED WITH:
Fadal Multi Processor CNC Control
Coolant System
Chip Conveyor

*Preliminary specifications, pending confirmation

This machine is listed for sale by Liberty Machinery Company located in Lincolnshire, Illinois
