22" JET® Industrial Belt Drill Press: IDP-22 - $RFQ

Item Number: #00098982
22&quot; JET&#174; Industrial Belt Drill Press: IDP-22





22" JET® Industrial Belt Drill Press: IDP-22

Stock Code:  354301
Price: $RFQ
Subcategory:

Miscellaneous Drills

Manufacturer:  Jet
Model:  IDP-22
Condition: New

CALL FOR AVAILABILITY AND BEST PRICING!

FEATURES:
CSA/CUS: Following strict guidelines and electrical requirements, these JET Drill Presses are CSA/CUS certified.
LED Machine Lamp
Spindle Guard
On/off switch located on front of the drill press head
Spindle is supported by high quality ball bearings
Heavy Duty construction
Cast iron table and base
Table Ground for Accuracy
Large Hand Grips designed with the users comfort in mind
Hinged metal belt and pulley cover coupled with quick adjustment motor mount allow rapid changing of spindle speeds
Rotating, 45° tilting, crank-operated worktable with quick release clamp
A 1/2" diameter external positive depth stop with three nut locking feature for quick adjustment
Adjustable tension spindle return spring
Drill chuck and key attach to the side of the drill press always within reach of the operator

STANDARD EQUIPMENT:
Ground Table
Spindle Safety Guard
Halogen Machine Lamp
Drill Chuck and Key

SPECIFICATIONS:
Drills to Center of Circle - Swing (in): 21-7/8
Drilling Capacity Cast Iron (in.): 1-1/4
Drilling Capacity Mild Steel (in.): 1
Column Diameter (in.): 3-5/8
Distance Column to Spindle (in.): 10-7/8
Number of Spindle speeds: 12
Range of Spindle Speeds (RPM): 175-3,050
Spindle Travel (in.): 4-13/16
Spindle Distance to Base (in.): 48-1/2
Distance Spindle to Table (max./in.): 28
Spindle Taper: MT-3
Quill Diameter (in.): 2-5/8
Chuck Size (in.): 5/8
Table Size (in.): 18-5/8 x 16-1/8
T-Slots Number and Size (in): 5/8" & 3
T-Slot Centers (in.): 3/4
Work Table Weight Capacity (lbs.): 176
Base Work Table area (in.): 21-1/2 x 18-5/16
Base Slots Number & Size (in.): 5/8" & 2
Base Dimensions (LxWxH/ in.): 22-5/8 x 19-7/16 x 3-3/8
Motor: 1-1/2 HP, 115/230V, 1Ph
Prewired: 115V
Net Weight: 319 lbs.
Gross Weight: 364 lbs.

Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 2 YEAR – LIMITED
