Year Built - 2008
Serial No. P082D0280
Type A04B-0319-B001#D5

SPECIFICATIONS:
Travels:
- X-Axis............14.6"
- Y-Axis............10.6"
- Z-Axis............10.2"
- U/V Axis............2.36" x 2.36"
Workpiece Size - Maximum............27.6" x 23.6" x 9.8"
Wokpece Weight - Maximum............1100 Lbs.
Inside Tank Dimensions............30.5" x 23.6"
Cutting Speed - Maximum............31 in²/hour
Table Feedrate............1 ~ 50 in/min
Wire Diameter............Ø 0.004 - 0.012"
Wire Spool Weight - Maximum............35 Lbs.
Wire Feedrate............0 ~ 590 in/min
Wire Tension............200 ~ 2500 grams
Postioning Accuracy............± 0.0001"
Auto Wire Feed............Standard
Dielectric Tank Capacity............145 Gallons
Submerged Depth - Maximum............9.84"
Electrics............200/220V/3Ph/50/60Hz
Pulse Generator............Standard
Machine Weight - Catalog............4,000 Lbs.
Machine Dimensions - Approximate............76" x 87" x 77"H

EQUIPPED WITH:
Fanuc Series 310is-WA CNC Touchscreen Control
Dielectric Filtration System
Inverter Chiller
Wire Reclaim Bin
Control Cabinet
Linear GlassScales (X & Y)
AI Pulse Control
AI Wire Break Repair Function
Servo Water Level Control
Twin AC Servo Wire Tension Control
Air Jet AWF
Challenger DT-3 152-415 Transformer (15 KVA)

*Preliminary specifications, pending confirmation

This machine is listed for sale by Liberty Machinery Company located in Lincolnshire, Illinois
