BAILEIGH Welding Table WJT-4747-HD
CALL FOR BEST PRICING!
The WJT-4747-HD has a table size of 47" x 47" and has a total of 5 mourning surfaces that use Industry standard 28mm holes that are spaced at 100mm to ensure the most options with the strongest holding power.
Made from 250 cast iron, the WJT-4747-HD welding jig table from Baileigh Industrial is made to withstand the rigors of any shop. All of Baileigh Industrial's welding tables are made to exact tolerances and maintain flatness of +/- .0025" and have a hardness rating of 140 to 160 Brinell.
47” x 47” table
Made from 250 Cast Iron
Brinell Hardness 140~160
5 Mounting Surfaces
2 ton weight capacity
Industry Standard 28mm Mounting holes
100mm hole spacing
Etched Position Marks
Working Table Size: 47" x 47"
Table Load Capacity: 2 Tons
Table Height: 33.5"
Table Flatness: +/- .0025"
Number of Mounting Surfaces: 5
Mounting Hole Size: 28mm
Mounting Hole Spacing: 100mm
Dimensions L x W x H: 50" x 50" x 50"
Shipping Weight: 1,045 lbs.
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
This machine is listed for sale by Sierra Victor Industries
located in Port Orange, Florida
