CINCINNATI DIAL TYPE VERTICAL MILL
PRICE: Loaded on Truck, Our Warehouse, York, PA …… $12,500.00

HMC Stock # 20209-P
Serial No.: 4A3V5T-3
Model No.: 315-16 DT
New: 1967

Table Size: 71-3/4" x 16-1/4"
Table Working Surface: 63-1/2"
(3) T-Slots: 3/16"
Longitudinal Table Travel: 34"
Cross Table Travel: 16"
Vertical Table Travel: 20"
Distance Spindle to Table Top: 3/4" to 16"
Throat Distance: 18"
Spindle Taper: #50
(24) Spindle Speeds: 16 to 1600 RPM
(32) Feeds: 3/8 to 90 IPM (Table and Cross)
3/16 to 45 IPM (Vertical)
Rapid Travels: 150 IPM (Longitudinal and Cross)
75 IPM (Vertical)

EQUIPPED WITH:
(2) Adjustable Vertical Knee Feed Stops
(4) Adjustable Table Feed Stops
Soft Saddle Ways in Good Condition
Table Climb Milling Feature
Bijur Central Way Lubrication System
Front Operational Controls
Power Up - Down Feed of Head
4-Position Turret Type Head Down Feed Stop System with Dial Indicator
Power Rapid Traverse to All Axes
(1) Manual Tool Draw Bar
Satin Chrome Graduated Dial on Each Axis
Manual Knee Crank Handle

ELECTRICAL:
15 HP Spindle Motor
5.5 HP Feed Motor
1/10 HP Coolant Motor
Wired for 3 Phase, 60 Cycle, 208/220/440 Volts

Overall Size: 91" LR x 98" FB x 101" High on 4" Blocks x 12,100 Lbs.

This machine is listed for sale by Hildebrand Machinery Co Inc located in York, Pennsylvania
