TABLE DIMENSIONS........... 36" X 14"
X-AXIS TRAVEL.............. 30"
Y-AXIS TRAVEL.............. 16"
Z-AXIS TRAVEL.............. 20"
SPINDLE SPEED.............. 12,000 RPM
SPINDLE MOTOR.............. 30 HP
SPINDLE TAPER.............. CAT 40
TOOL CAPACITY.............. 30 ATC

EQUIPPED WITH:
HAAS NEXTGEN CONTROL (TOUCH SCREEN)
RENISHAW WIRELESS INTUITIVE PROBING SYSTEM (WIPS)
THROUGH-SPINDLE COOLANT READY
SIDE-MOUNT TOOL CHANGER (30 ATC)
12,000 RPM SPINDLE
MULTI-AUGER CHIP REMOVAL SYSTEM
CHIP TRAY FILTER KIT
AUTOMATIC AIR GUN
WINDOW AIR BLAST
VISUAL PART PROGRAMMING SYSTEM
COORDINATE ROTATION & SCALING
MEDIA DISPLAY M-CODE (M130)
HIGH-SPEED MACHINING
SPINDLE ORIENTATION
RIGID TAPPING
SAFE RUN
MACROS
1GB MEMORY
ETHERNET
USB PORT
HAASDROP
HAASCONNECT: REMOTE MONITORING
WIFI CONNECTION FOR THE HAAS CONTROL
HEAVY-DUTY LOW-VOLT TRANSFORMER
EARLY POWER-FAILURE DETECTION MODULE

** AS OF OCTOBER 2022, POWER ON TIME – 1,136 HOURS

** FULL REPLACEMENT COST, AS EQUIPPED - $88,000
** MACHINE CUT PRIMARILY ALUMINUM & SOME STEEL
** IN PLANT, UNDER POWER, AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE

** TOOL HOLDERS & VICES SHOWN ARE NOT INCLUDED
** (2) 2021 HAAS VF-2SS MACHINES AVAILABLE IN THE SAME SHOP

This machine is listed for sale by Clark Machinery Sales located in Hunt Valley, MD, Maryland
