TABLE DIMENSIONS............. 15.75" X 15.75"
TABLE CAPACITY............... 660 LBS
X-AXIS TRAVEL................ 30"
Y-AXIS TRAVEL................ 18.11"
Z-AXIS TRAVEL................ 18.11"
SPINDLE SPEED................ 15,000 RPM
SPINDLE MOTOR................ 22 HP
SPINDLE TAPER................ CAT 40 BIG PLUS
TOOL CAPACITY................ 48 ATC
RAPID TRAVERSE RATE.......... 1575 IPM
CUTTING FEEDRATE............. 1260 IPM
APPROX MACHINE WEIGHT........ 17,000 LBS
APPROX MACHINE DIMENSIONS.... 85" X 111" X 116"

EQUIPPED WITH:
OKUMA OSP P300MA-H 5-AXIS CNC CONTROL
TRUNNION TABLE
MP SYSTEMS - HIGH PRESSURE THRU SPINDLE COOLANT, UP TO 12 GPM, UP TO 300 PSI
HIGH SPEED MACHINING
RENISHAW SPINDLE PROBE
SPINDLE AIR BLOW
MAYFRAN CLEANSWEEP RM CHIP CONVEYOR

**
* DOUBLE CAST IRON MACHINE BED
* PRE-TENSION BALL SCRES
* HYPOID GEAR DRIVE IN THE TRUNNION SYSTEM - OFFERING EXCELLENT ACCURACY
*

HOURS OF USE (AS OF MAY, 2022)
- POWER ON TIME: 8,477 HOURS
- NC RUNNING TIME: 3,482 HOURS
- SPINDLE REVOLUTION TIME: 3,239 HOURS
- CUTTING TIME: 2,213 HOURS

** AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE

BASE PRICE FOR ABOVE MACHINE IF PURCHASED NEW TODAY: $353,000

This machine is listed for sale by Clark Machinery Sales located in Hunt Valley, MD, Maryland
