X-AXIS TRAVEL................. 40"
Y-AXIS TRAVEL................. 25"
Z-AXIS TRAVEL................. 25"
B-AXIS (TILT) TRAVEL.......... +120 DEGREES/ -35 DEGREES
C-AXIS (ROTATION) TRAVEL...... 360 DEGREES
PLATTER DIAMETER.............. 25"
MAX WEIGHT ON PLATTER......... 1,000 LBS
SPINDLE SPEED................. 15,000 RPM
SPINDLE MOTOR................. 30 HP
SPINDLE TAPER................. HSK-A63 (DUAL CONTACT)
RAPID TRAVERSE RATE (X/Y/Z)... 900 IPM
TOOL POSITIONS................ 50 ATC (SIDE-MOUNT)

EQUIPPED WITH:
RENISHAW WIRELESS INTUITIVE PROBING SYSTEM (WIPS)
THROUGH-SPINDLE COOLANT (300 PSI)
THROUGH-TOOL AIR BLAST
15,000 RPM SPINDLE
50 TOOL POSITIONS - HSK-A63 (DUAL CONTACT)
ROTARY SCALES (B & C AXIS)
CHIP CONVEYOR (BELT-TYPE)
ENCLOSURE EXHAUST SYSTEM
AUXILIARY COOLANT FILTER
PROGRAMMABLE COOLANT
REMOTE JOG HANDLE
DYNAMIC WORK OFFSET & TOOL CENTER POINT CONTROL
COORDINATE ROTATION & SCALING
SECOND HOME POSIITION
HIGH-SPEED MACHINING
SPINDLE ORIENTATION
RIGID TAPPING
MACROS
WIFI CONNECTION
ETHERNET
USB PORT
TOP COVER
95 GALLON COOLANT TANK

HOURS OF USE (AS OF 4/2022):
- FEED CUTTING TIME: 1,145 HOURS


** IN PLANT, UNDER POWER, AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE

**** ALSO AVAILABLE IN SAME PLANT:
- 2015 HAAS DT-1 W/ 20,000 RPM SPINDLE
- 2011 HAAS DT-1 W/12,000 RPM SPINDLE
- 2012 HAAS ST-30SSY W/HAAS BARFEED

This machine is listed for sale by Clark Machinery Sales located in Hunt Valley, MD, Maryland
