Year Built - 2009

SPECIFICATIONS:
Turning Diameter - Maximum............11.4"
Machining Length - Maximum............19.7"
Swing Over Bed - Maximum............21.7"
Distance Between Spindles............32.3"
Bar Capacity............2.67"
Travels:
- X-Axis............8"
- Z-Axis............22.8"
- B-Axis............22.8"
Spindle:
- Speed - Maximum............5000 RPM
- Nose............A2-6
- Bore Diameter............2.67"
- Motor Power............25 HP
- Chuck Size............10"
Sup-Spindle:
- Speed - Maximum............6000 RPM
- Power............7.5 HP
- Chuck Size............4"
Rapid Traverse Rates:
- X1, X2............945 ipm
- Z1, Z2............1181 ipm
- W............1181 ipm
C-Axis Index............0.001°
Turret Configuration............12 Stations
Turret Rotary Tool Power............7.5 HP
Turret Index............1 Second
Dimensions - Approximate............126"L x 65"W x 70"H
Weight - Approximate............10,800 Lbs

EQUIPPED WITH:
Fanuc 18i-TB CNC Control
Sub Spindle
ATS ML-580 Bar Feeder
Royal FX550 Mist Eliminator
Live Tooling
Collet Chuck Attachment
Coolant System
Chip Conveyor
Tool Touch Probe

*Preliminary specifications, pending confirmation.

This machine is listed for sale by Liberty Machinery Company located in Lincolnshire, Illinois
