18" Swing 80" Centers Sharp 1880LV ENGINE LATHE, D1-8 Camlock w/3-1/16" bore; variable spindle spds - $23,990

Item Number: #00019428
18&quot; Swing 80&quot; Centers Sharp 1880LV ENGINE LATHE, D1-8 Camlock w/3-1/16&quot; bore; variable spindle spds

18" Swing 80" Centers Sharp 1880LV ENGINE LATHE, D1-8 Camlock w/3-1/16" bore; variable spindle spds
Stock Code:  136734
Price: $23,990
Subcategory:

Press Brake - New Standard Tooling / Dies

Manufacturer:  Sharp
Model:  1880LV
Condition: Used

NEW SHARP MODEL: 1880LV PRECISION LATHE


VARIABLE SPEED





*** MADE IN TAIWAN ***





 STANDARD EQUIPMENT:


3-Jaw Chuck (10”)


Face Plate (16”)


American Tool Post


Follow Rest ( 0.59” – 3.15”)


Steady Rest w/ bronze tip (1/2 - 6”)


Coolant System


Full Length Splash Guard


Halogen Work Light


Micrometer Carriage Stop


Longitudinal Carriage Stops


Machine is set only for  220 V. Needs an optional transformer for 440V applications.


Tail Stock & Tool Kit includes:


Machine Manual, Half Nut Wrench, Wrench 17m, 19m, Set of 6 Allen wrenches, Phillip Screw Driver, Flat Head Screw Driver, Oil can, Grease Gun, Rear Way Cover Bracket, 2 sets of dead center, 2 sets of dead center, Pin for Indicator, Can of Paint





FEATURES:


D1-8 Camlock, 3.18” Hole


Direct Selection For Inch/Metric Threads


One Piece Cast Meehanite Bed


7-1/2 Hp Spindle Motor


Digital Variable Speed (20-2,000 Rpm)


Digital Variable Head on “LV” Models Wired at 220V only.  440V Optional





SPECIFICATIONS:


Capacity




Swing Over Bed: 18.5”


Swing Over Cross Slide: 11”


Center Height: 9.25"


Swing Over Gap: 27-1/8”


Width of Gap: 11.75"


Distance Between Centers: 86.6”







Headstock




Spindle Nose Type: D1-8 Camlock


Spindle Bore: 3-1/16”


Spindle Speeds (DIGITAL VARIABLE SPEED: 20-2,000 rpm


Taper of  Spindle Bore: MT#6


Taper of Center: MT#5







Threads and Feeds




Longitudinal Feeds – in/rev (18): 0.002 - 0.032”


Cross Feeds – in / rev {#}: 0.0001 –0.0094” {12}


Inch Threads (#): 4-56 tpi {36}


Metric and Module Threads {#}: 0.5-7mm {17}


D.P. Threads (36): 4-56 mm


Leadscrew Pitch, Diameter: 4 tpi, 1-3/8”







Carriage




Cross Slide Travel: 9-7/8”


Compound Rest Travel: 5.3”


Compound Width: 5.0”







Bed




Bed Length: 110”


Bed Width: 11-3/4”







Tailstock




Quill Travel (graduated: 5-1/2”


Quill Diameter: 2-11/16”


Quill Taper: MT#4







General




Spindle Motor (220V or 440V, 60, 3): 7-1/2 hp


Net Weight (approx.): 5,300 LBS







Dimensions ( L X W X H): 134.6” X 21” X 48”




Standard Color: Gray







Electrical:




Voltage :         **230V




  **(440V requires optional transformer $1,275)















Phase:          3 phase







Total Power Consumptions




¨ 230V                              8KVA/25 amps




¨ 460V                             8KVA/12.5 amps





FOR MORE INFORMATION: Call Terry at 973-497-7612
