20" Swing 80" Centers Birmingham YCL-2080 ENGINE LATHE, D1-8 with 3-1/8" spindle bore - $16,965

Item Number: #00008205
20&quot; Swing 80&quot; Centers Birmingham YCL-2080 ENGINE LATHE, D1-8 with 3-1/8&quot; spindle bore

20" Swing 80" Centers Birmingham YCL-2080 ENGINE LATHE, D1-8 with 3-1/8" spindle bore
Stock Code:  139057
Price: $16,965
Subcategory:

Press Brake - New Standard Tooling / Dies

Manufacturer:  Birmingham
Model:  YCL-2080
Condition: Used

NEW BIRMINGHAM 20" x 80" PRECISION GAP BED LATHE


MODEL: YCL-2080











FEATURES:


10 HP MAIN MOTOR


ONE PIECE CAST IRON BASE


D1-8 SPINDLE WITH 3-18" SPINDLE BORE


NO CHANGE GEARS REQUIRED


12 SPEEDS FROM 45 - 1,600 RPM


60 KINDS OF INCH THREADS FROM 112 - 2 TPI


47 KINDS OF METRIC THREADS FROM 0.2 - 14MM


MAIN SPINDLE HARDENED & PRECISION GROUND


BED MADE OF FINE GRAIN HIGH TENSILE CAST IRON


BEDWAYS INDUCTION HARDENED & PRECISION GROUND


ALL GEARS & SHAFTS HARDENED & PRECISION GROUND


MAIN SPINDLE SUPPORTED AT 3-POINT BY PRECISION BEARINGS








SPECIFICATIONS:


MAX. SWING OVER BED:   20"


DISTANCE BETWEEN CENTERS:   80"


MAX. EFFECTIVE CUTTING LENGTH:   75.5"


MAX. SWING OVER CROSS SLIDE:   11-7/8"


MAX. SWING IN GAP:   29"


EFFECTIVE LENGTH IN GAP:   6"


WIDTH OF BED:   13-3/4"


SPINDLE NOSE:   D1-8


DIAMETER OF SPINDLE THRU BORE:   3-1/8"


TAPER OF SPINDLE CENTER:   MT#7 / MT#5


SPINDLE SPEEDS, 12 STEPS: 25,35,55,80,120,170,235,350,525,700,1100,1600 RPM


LONGITUDINAL FEEDS: 35 KINDS, 0.0022" - 0.0612" REV.


CROSS FEEDS: 35 KINDS, 0.00048" - 0.01354" REV.


METRIC THREADS: 47 KINDS, 0.2 - 14MM


INCH THREADS: 60 KINDS, 112 - 2 TPI


MODULE THREADS: 39 KINDS, 0.1 - 7MM


DIAMETRAL PITCH THREADS: 50 KINDS, 4 - 112 DP


MAX. TRAVEL OF CROSS SLIDE: 12-15/16"


MAX. TRAVEL OF TOP SLIDE: 5-1/8"


4-WAY TOOL POST SIZE: 1" X 1"


LONGITUDINAL LEADSCREW DIA/PITCH: DIA. 1-5/8" / 4 TPI


DIAMETER OF TAILSTOCK QUILL: 3"


TAPER OF TAILSTOCK QUILL CENTER: MT#5


MAX. TRAVEL OF TAILSTOCK QUILL: 7"


POWER OF MAIN MOTOR: 10 HP, 230/460V/60HZ, 3 PHASE PREWIRED 230V


POWER OF COOLANT PUMP: 1/8 HP, 230/460V/60HZ, 3 PHASE PREWIRED 230V








STANDARD EQUIPMENT:





3 JAW CHUCK


4 JAW CHUCK


FACE PLATE


STEADY REST WITH ROLLER JAWS


FOLLOW REST


GAP


4 WAY TOOL POST


THREADING CHASING DIAL


(2) DEAD CENTERS


REDUCING SLEEVE


FULL LENGTH SPLASH GUARD


ONE PIECE CAST IRON BASE


FOOT BRAKE


HALOGEN WORK LIGHT


COOLANT SYSTEM


LEVELING PADS


4 POSITION AUTO KICK OUT LONGITUDINAL CARRIAGE STOP


TOOL BOX


TAPER TURN ATTACHMENT








OPTIONAL EQUIPMENT (CALL FOR PRICING):





10" LARGE STEADY REST W/ROLLER JAWS FOR YCL-2060/80/120 & YCL2260/80/120


5C HAND LEVER TYPE COLLET CLOSER "JFK" USA


5C COLLET CHUCK (FRONT OPEATE) D1-6 MOUNT


DIGITAL READOUT: NEWALL DP-700 OR ACU-RITE OR UNIQ IMPORT


FOR MORE INFORMATION: Call Kori at 973-497-7567
