BAILEIGH Variable Speed Vertical Mill VM-1054E-VS
|Table width: ||54"
|Table length: ||10"
CALL FOR AVAILABILITY AND BEST PRICING!
The VM-1054E-VS is a variable speed milling machine that runs from 60 to 4,200 rpm. By selecting the right speed tooling life is lengthened and cut quality improves, both of which save money. Baileigh Industrial selected an ISO 40 taper for its spindle to help improve performance as well. A larger spindle is stronger and has tighter tolerances over a longer period of time. Rigidity is also very important on a mill that is why Baileigh Industrial went with only the best castings to make the base and frame. The stronger you make he platform the better the cutting is. Table size is another very important component when deciding which milling machine to buy and VM-1054E-VS has a 10” x 54” table that has been hardened, ground, polished, and coated with a special coating called Turcite B to extend life and help eliminate corrosion.
All three axis are powered on the VM-1054E-VS making it easy on the operator. Another nice feature is the two axis digital readout that comes standard. This digital readout is accurate to 1/10 of 1 thousandth of an inch. A flood coolant system, air draw bar, and central lubrication system are all factory installed on the VM-1054E-VS.
Table Size: 10" x 54" (254 x 1371mm)
Spindle: ISO 40
Spindle Speeds: 60~4,200RPM
Quill Dia.: 3-11/32" (85mm)
Spindle Bearings: 7207
Spindle Travel: 5" (127mm)
Table to Spindle Nose (Min.): 4" (102mm)
Table to Spindle Nose (Max.): 17" (432mm)
Knee Travel: 13" (330mm)
X Travel: 32" (813mm) Power feed
Y Travel: 13-3/4" (350mm) Power feed
Head Tilt (L&R): 90°
Head Pivot (F&B): 45°
Turret Rotation (CW & CCW): 165°
Ram Travel: 20" (508mm)
Quill Auto Feed Speeds: .003" .0015" .006"
T-Slots: 5/8" (16mm)
Coolant Capacity (Max): 5.3 Gallons
Work Light: LED
NRTL: CSA Ready
Horsepower: 3 HP
Voltage: 220V, 60hz, 1ph
Shipping Dimensions: 60" x 60" x 87"
Shipping Weight: 3,000 lbs
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
