New - 2006
Serial No. 92516

CATALOG SPECIFICATIONS:
I.D. Range............0.060" - 6.500"
Length Range - Maximum............16"
Spindle:
- Speeds (12)............200 - 1,600 RPM
- Motor............1/2 HP
Electrics............115V/1Ph/60Hz
Honing Oil Filter:
- Capacity............16 Gals.
- Pump............Utilizes spindle drive motor
Dimensions (Approximate):
- Machine............32"(L-R) x 60"(F-B) x 63"(H)
- Honing Oil Filter............13"(L-R) x 29"(F-B) x 33"(H)
- Cabinet............37″(L-R) x 25″(F-B) x 68″(H)
Weights (Approximate):
- Machine - Dry............510 Lbs.
- Honing Oil Filter - Dry............200 Lbs.
- Cabinet............600 Lbs.

EQUIPPED WITH:
Sunnen PF-150 honing oil filter unit
Sunnen LN-650 lighted mandrel cabinet
Nearly complete range of Sunnen honing units, stones, and mandrels
Sunnen KKN-100 Square Honing Fixture for parts with very short holes where bore diameter is more than three times the length, and the piece has a flat face.
Mandrels:
- 3H-P28-2250WF
- 2H-P28-2125WF
- 2H-P28-1875WE
- 5G-P28-1750WE
- 2G-P28-1750WE
- (2) 2G-P28-1625WD
- (3) 2G-P28-1500WD
- 4G-P28-1375WC
- 2G-P28-1375WC
- (2) 2G-P28-1250WB
- 5G-P28-1187VB
- 2G-P28-1125VB
- 2G-P28-1062VA
- 3PL-1062M
- 5G-P20-781UA
- 3G-P20-750UA
- 3G-P20-625AS
Lot of Misc Sunnen Truing Sleeves
Dual pressure dials for light and heavy cutting
Adjustable pedal bar - honing dial
Self-energizing band type spindle brake
Foot Treadle
Sunnen Honing Oil
Machine Manual
Misc. Mandrels, Stone Retainers, Stones, Belts, & Tooling

*Catalog specifications, pending confirmation

This machine is listed for sale by Liberty Machinery Company located in Lincolnshire, Illinois
