New - 2012
Serial No. 1L1-1532

SPECIFICATIONS:
Diameter Range (ID):
- Manual Stroking............0.060" - 6.50"
- Power Stroking............0.060" - 4.00"
Automatic Sizing............1.25" - 2.00"
Stroke Length............0.236" - 6.70"
Spindle Speeds (Infinitely Variable)............200 - 3000 RPM
Stroke Rate............60 - 350 SPM
Motors:
- Spindle............3 HP
- Stroker............1 HP
- Pump............1/3 HP
Coolant Flow............3 GPM
Coolant Capacity............28 Gallons
Pneumatic Requirements............80 PSI
Electrical............230V/3Ph/50/60 Hz
Dimensions - Approximate............64" x 48" x 75" H
Weight - Approximate............1875 Lbs.

EQUIPPED WITH:
- Auto Size Control Capabilities (Less Assembly/Probe)
- Auto Stone Wear Compensation
- Feed Regulator System
- Feed Pressure Flexibility
- Universal Workholding Fixture
- Detachable Coolant Cart
- PF-150 Coolant Filtration System
- PF-150 Coolant Cartridge Filters (4)

*Preliminary Specifications Subject to Verification

This machine is listed for sale by Liberty Machinery Company located in Lincolnshire, Illinois
