BAILEIGH Air/Hand Operated H-Frame Shop Press HSP-30A
H - Frame Presses
CALL FOR BEST PRICING!
The HSP-30A pneumatic shop press offers the same high-value features and steel construction of our HSP-20A—but with 30 tons of force!
21-3/16” working width.
5.9” cylinder stroke.
Industrial-grade hydraulic parts ensure smooth, dependable use for years.
Cylinder can move left and right within the frame, depending on orientation of the job.
You have the option to work the HSP-30A manually, if you need finer control.
Comes standard with a set of V-blocks.
Rigid, fully-welded steel main frame eliminates flexing at full force to deliver accurate results.
Typically in stock for fast deliveries.
Baileigh covers this H-frame press with a 1-year parts warranty and lifetime technical support by phone.
Max Capacity: 30 ton
Working Width: 22.5”
Moveable Cylinder: Yes
Cylinder Stroke: 5.9”
Cylinder Diameter: 4.5”
Piston Rod Diameter: 3.5”
Piston Head Diameter: 2.375”
Distance From Table To Ram: Min. 5.94" - Max. 40.59"
Power Requirement: Pneumatic / Manual
Shipping Dimensions: 74" x 31" x 12"
Shipping Weight: 450 lbs
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
