Max Swing Over Bed 20 1/2"
Max Workpiece Length 90"
Max Travel of Top Slide 6"
Max Travel of Cross Slide 11"
Spindle length w/o Chuck 17"
Effective Length in Gap to Chuck Jaws 3 1/2"
Spindle Bore 3 1/8", D1-8
Spindle Speed 40-2,000 RPM / 12 STEPS
Main Motor 7 1/2 HP, 220V or 440V, 3 Phase
Coolant Pump 1/8 HP, 220V or 440V, 3 phase, 2 Gal Coolant
Overall Dimensions (approx.) 139 x 41 x 59"H
Weight (approx) 5150

Made in Taiwan-100% made in Taiwan, by top manufacturer with very high level of quality

One piece solid casting base, Meehanite high performance cast iron

Machine bed is made of Meehanite casting – high performance cast iron



Equipped with:

Free CARMAR DRO, installed
Automatic kick-out longitudinal carriage stop system
10” 3-jaw chuck with top reversible jaws, direct mount
16” Face plate
9” steady rest with roller jaws
4” follow rest with roller jaws
Removeable gap
4-way tools post
Foot brake
LED Work light
coolant system
full length rear splash guard
Dead centers
Thread chasing dial
Reducing sleeve MT6/MT5 for spindle
Tool box and leveling pads
1 Year Warranty on Parts


Standard Features:

ISO 9001 certified
Large spindle bore 3-1/8”
Heavy Duty spindle D1-8
Heavy Duty guideway width 12”
Spindle speeds from 40-2,000 rpm, 12 speeds
Threading and feeding rate change without changing gears
Spindle is balanced, hardened and precision ground
Spindle is supported at 3-point by high precision bearings
All gears and shafts are hardened and precision ground
Guideways induction hardened and precision ground
Automatic lubrication system in headstock and feed box

*Disclaimer* Please note this machine is incompatible with the use of a rotary phase converter. Any attempt to purchase, install, or employ one, whether carried out by you or a professional service company, will automatically void the warranty. It is crucial to understand that any such actions are entirely the responsibility of the buyer.

This machine is listed for sale by Manufacturing Solutions located in SANTA ANA, California
