Max Swing Over Bed 16 1/16"
Max Workpiece Length 60"
Max Swing Over Cross Slide 10 1/4"
Bed Width 10 1/4"
Spindle Bore 2 1/16" D1-6
Spindle Speed 45 - 1,800 RPM
Range of Longitudinal Feeds 0.0018 - 0.07 IPR, 42 Kinds
Range of Cross feeds 0.0009-0.03 IPR, 42 kinds
Main Motor 6 HP, 220V/20A, 3 Phase
Coolant Pump 1/8 HP, 220V, 3 Phase
Overall Dimensions (approx.) 100" x 32.2" x 56"H
Weight (approx) 4850 lbs.

Equipped with:

SINO DRO (installed)
Taper turning attachment (installed)
8” 3-jaw chuck with one set of reversible jaws
10” 4-jaw chuck
12” Face plate
5 1/2” large steady rest with roller jaws (bearings)
Oil pump on Apron for all guideways and leadscrews
2” follow rest with roller jaws (bearings)
Removeable gap
4-way tools post
Foot brake
Halogen Work light and coolant system
Full length splash guard
(2) dead centers and (1) reducing sleeve MT6/MT4
Thread chasing dial
Tool box and leveling pads
1 Year Warranty on Parts

This machine is listed for sale by Manufacturing Solutions located in SANTA ANA, California
