JET J-A3816 6-Speed Floor Model Drill Press 115/230V 1Ph - $RFQ

Item Number: #00076646
JET J-A3816 6-Speed Floor Model Drill Press 115/230V 1Ph

JET J-A3816 6-Speed Floor Model Drill Press 115/230V 1Ph
Stock Code:  354500
Price: $RFQ
Subcategory:

Drilling & Tapping Machines

Manufacturer:  Jet
Model:  J-A3816
Condition: New

CALL FOR BEST PRICE!

FEATURES:
Constructed to provide a solid base for drilling
Offers a grater range in spindle speeds than others in this class
Larger quill provides greater accuracy
Large production work table give the operator the room to work and support
for the job
3" Column for head support, while the quill is also supported to lessen deflection

SPECIFICATIONS:
Distance Column to Spindle (in.): 15
Drilling Capacity Cast Iron (in.): 5/8
Drilling Capacity Mild Steel (in.): 1/2
Spindle Travel (in.): 6
Spindle Taper: MT-2
Range of Spindle Speeds (RPM): 375, 625, 1125, 1950, 3400, 5000
Table Dimensions: 15 x 18
Table Travel (in.): 16-3/4
Max Distance Spindle to Table ( in.): 25-3/4
T-Slots Number and Size (in.): 2 & 1/2
T-Slot Centers (in.): 5-5/16
Spindle Distance to Base (in.): 44-1/2
Column Diameter (in.): 3
Work Table Weight Capacity (lb.): 90
Base Work Table (in.): 12-1/8 x 1-13/16
Base Slots Number & Size (in.): 2 & 1/2
Base Dimensions (in.): 20-7/8 x 14-3/16 x 3-1/8
Motor: 1HP, 115/230VAC, 1ph, Prewired 115V
Overall Dimensions (in.): 30 x 20 x 71
Weight (lb.): 394

Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 2 YEAR – Limited
