SPECIFICATIONS
TRAVELS:
-X AXIS: 8.50"
-Y AXIS: 4.00"
-Z AXIS: 23.75"

RAPID TRAVERSE RATES
-X AXIS: 1,181 IPM
-Y AXIS: 394 IPM
-Z AXIS: 1,181 IPM

6" CHUCK
MAX SWING: 27.4"
STANDARD MACHINING DIAMETER: 9.25"
MAX MACHINING DIAMETER: 13.5"
MAX DISTANCE BETWEEN SPINDLE END & TURRET END: 24.5"
BAR WORK CAPACITY: 1.65"
MAX SUPPORT WEIGHT (CHUCK WORK/SHAFT WORK): 440 LBS
SPINDLE SPEED: 6,000 RPM
SPINDLE NOSE: A2-6
SPINDLE THROUGH HOLE DIAMETER: 2.44"
SPINDLE MOTOR (25%ED/CONT): 20/15 HP
MAX SPINDLE TORQUE: 91 FT/LBS

2ND SPINDLE
CHUCK SIZE: 5"
SPINDLE SPEED (40%ED): 6,000 RPM/10 HP
SPINDLE NOSE: A2-5
SPINDLE BORE: 2.09"

MILLING SPINDLE: 4,500 RPM/5 HP
NUMBER OF TOOLS: 12

TURNING TOOL SIZE
OUTSIDE: 1"
INSIDE: 1.5"
INSIDE 2ND: 1.0"

MACHINE DIMS: 1024" X 66.5" X 67.9"
MACHINE WEIGHT: 12,125 LBS

EQUIPPED WITH
8" CHUCK MAIN SPINDLE
6" CHUCK SUB SPINDLE
6000 RPM ROTARY TOOL Y -AXIS MILLING
AUTOMATIC PARTS CATCHER
CHIP CONVEYER
AUTOMATIC TOOL EYE
WORK PIEACE CONVEYER FOR PARTS CATCHER
1000 PSI MAZAK SUPERFLOW PREP
MAZAK SUPER FLOW S8 HIGH PRESSURE
LIVE TOOLS
COOLANT FLUSH ON SUB SPINDLE

This machine is listed for sale by Machinery Resources International located in Simi Valley, California
