SPECIFICATIONS
TRAVELS:
-X AXIS: 10.2"
-Y AXIS: +/- 2.0"
-Z AXIS: 31.3"

SWING OVER BED: 36.2"
SWING OVER CROSS SLIDE: 29.2"
MAX TURNING DIAMETER: 14.4"
STANDARD TURNING DIAMETER: 10.6"
MAX. TURNING LENGTH: 27.7"
BAR WORK CAPACITY: 3.1"

SPINDLE 1
MAX SPINDLE SPEED: 4000 RPM
MOTOR: 25/20 HP
SPINDLE NOSE: A2-8
THROUGH-SPINDLE HOLE DIAMETER: 3.6"

SPINDLE 2
MAX SPINDLE SPEED: 6000 RPM
MOTOR: 15/10 HP
SPINDLE NOSE: A2-5
THROUGH-SPINDLE HOLE DIAMETER: 1.7"

NO. OF TOOL STATIONS: 12
MAX ROTARY TOOL SPINDLE SPEED: 6,000 RPM
ROTARY MOTOR: 7.5/5HP
RAPID TRAVERSE RATE: XZB: 1181 IPM / Y: 393.7 IPM
FLOOR SPACE: 156" X 82" X 86"
WEIGHT: 12,000 LBS EST.
EQUIPPED WITH
DMG MORI M730BM CONTROL
TOOL PRESETTER
TOOL BREAKAGE DETECTION
PARTS CATCHER
PARTS CONVEYER
SUB SPINDLE
Y-AXIS
CHIP CONVEYOR - HINGE TYPE
KITAGAWA 6" CHUCK (SPINDLE)
ATS S30TLS COLLET TYPE CHUCK ON MAIN SPINDLE
BARFEED INTERFACE
6 FOOT MAGAZINE ATS BARFEED

This machine is listed for sale by Machinery Resources International located in Simi Valley, California
