SPECIFICATIONS:

TRAVELS:
X AXIS TRAVEL: 9.45"
Z AXIS TRAVEL: 63.19"
MAX TURNING DIAMETER: 16.8"
MAX TURNING LENGTH: 61.42"
MAX BAR CAPACITY: 3.5"
SWING OVER SLIDE: 19.7"
SWING OVER BED: 23.6"
DISTANCE BETWEEN CENTERS: 35.5"
RAPID TRAVERSE X AXIS: 472 IPM
RAPID TRAVERSE Z AXIS: 590 IPM
SPINDLE NOSE: A2-8
SPINDLE BORE: 4.13"
SPINDLE SPEED: 35-2500 RPM
SPINDLE MOTOR: 30 HP
TURRET CAPACITY: 12 STATIONS
TURRET INDEX TIME: 0.5 SECOND
TAILSTOCK BODY TRAVEL: 58.86"
TAILSTOCK QUILL DIA.: 5.12"
TAILSTOCK QUILL STROKE: 4.72"
TAILSTOCK TAPER: MT-5

EQUIPPED WITH:

CHIP CONVEYER
TAILSTOCK
TOOL SETTER
ALL AVAIABLE TOOLING

This machine is listed for sale by Machinery Resources International located in Simi Valley, California
