TRAVELS:
X-AXIS: 180 MM
Z-AXIS: 530 MM

CAPACITY:
MAXIMUM SWING: 480 MM
STANDARD TURNING DIAMETER: 216 MM
MAXIMUM TURNING DIAMETER: 320 MM
MAXIMUM TURNING LENGTH: 520 MM

SPINDLE:
SPINDLE SPEED RANGE: 4000 MM
NUMBER OF SPINDLE SPEED RANGE: 1
TYPE OF SPINDLE NOSE: JIS A2-6
SPINDLE TAPER HOLE TYPE: 75 MM 1/20 TAPER
SPINDLE BEARING INNER DIAMETER: 100 MM
THROUGH SPINDLE HOLE DIAMETER: 63 MM

MOTORS:
SPINDLE DRIVE MOTOR: 11/7.5KW ( a 15)
FEED MOTORS:
X: 0.6KW (a C6/2000)
Z: 2.1KW (a 12/2000)
HYDRAULIC PUMP MOTOR: 1.5KW
COOLANT PUMP MOTOR: 0.4KW

TAIL STOCK:
TAIL STOCK TRAVEL: 435 MM
TAIL STOCK SPINDLE DIAMETER: 90 MM
TAPER HOLE OF TAIL STOCK SPINDLE: MT NO. 5
TAIL STOCK SPINDLE TRAVEL: 120 MM

TANK CAPACITY:
HYDRAULIC PUMP MOTOR: 1.5KW
COOLANT PUMP MOTOR: 0.4KW

TOOL SIDE:
TYPE OF TOOL SIDE: 12 STA. TURRET
NUMBER OF TOOLS ON TOOL SIDE: 12
SQUARE SHANK HEIGHT OF SINGLE POINT TOOLS: 25 MM
SHANK DIAMETER OF BORING BARS: 40 MM

MACHINE SIZE:
MACHINE HEIGHT: 1770 MM
FLOOR SPACE: 2240 MM X 1645 MM
MASS OF MACHINE WITH NUMERICAL CONTROL: 4300KG

Equipped With:

8" CHUCK
FANUC CONTROL
TOOL SETTER
CHIP CONVEYER
TAILSTOCK

This machine is listed for sale by Machinery Resources International located in Simi Valley, California
