Specifications

TRAVELS:
X- AXIS: 7.7"
Z- AXIS: 23.2"
Y- AXIS: 3.9"
SWING: 32.1"
SWING OVER CROSS SLIDE: 26.73"
MAX. DIAMETER OF PART: 10.24"
MAX. DISTANCE BETWEEN CENTERS: 24.41"
MAX. TURNING LENGTH: 20.87"
SPINDLE NOSE: A2-8
SPINDLE RPM: 35-3,500
SPINDLE HP: 20/15
SPINDLE POSITIONING: 0.001"
BORE THRU SPINDLE: 3.1"
MAX. BAR CAPACITY: 2 5/8"
Equipped With

MF-T6 CONTROL
LCD TUBE-STYLE MONITOR REPLACEMENT
TAILSTOCK
TOOL PRESETTER
LIVE TOOLING

This machine is listed for sale by Machinery Resources International located in Simi Valley, California
