Specifications

TRAVELS:
X-AXIS: 10.2"
Z-AXIS: 31.3"
C-AXIS INDEX: .001 DEGREE
TURRET INDEX: (SINGLE STEP) 0.27 SECONDS
MACHINE DIMENSIONS: (L X W X H) 156.3" X 80.8" X 74.8"
MACHINE WEIGHT: 12,000 LBS.
MAX TURNING DIAMETER: (MAX / STD) 14.4" / 10.6"
SPINDLE TORQUE: 441.8 FT. LBS.
TAIL-STOCK TAPER: MT#5
CHUCK SIZE: 10"
MAX DIAMETER BAR CAPACITY: 3.1"
MAX SWING OVER BED / COVER / CARRIAGE: 31" / 23" / 21.3"
MAX MACHINING LENGTH: 27.7"
SPINDLE MOTOR: 24.7 / 20 HP
SPINDLE SPEED: 4000 RPM
SPINDLE NOSE: A2-8
SPINDLE BORE: 3.6"
TOOLS: 12 (ALL LIVE)
MILLING MOTOR: 7.5 HP
MILLING SPEED: 6000 RPM
RAPID TRAVERSE RATES: 1181 IPM
Equipped With

MORIC MSX-853 IV (MITSUBISHI 730BM) CNC CONTROL
10.4" COLOR TFT
C-AXIS MILLING CAPABILITY
10" HYDRAULIC CHUCK
DIGITAL TAILSTOCK
BUILT-IN INTEGRAL MILLING SPINDLE MOTOR
SERVO DRIVEN TURRET
TOOL PRESETTER
CHIP BLASTER (1000 PSI)
TURBO CHIP CONVEYOR (SIDE EXIT)
SLANT BED BOX WAY CONSTRUCTION
MANUFACTURE DATE JULY 2012

This machine is listed for sale by Machinery Resources International located in Simi Valley, California
