Specifications:
ANW-4100 SPECIFICATIONS:
RECOMMENDED WORK SIZE: MM[INCH] 300DIAMETER X 120 [11.8DIAMETER X 4.7]
SPINDLE DIAMETER: MM[INCH] 120DIAMETER [4.7DIAMETER]
SPINDLE NOSE: A2-8
SPINDLE BORE: MM[INCH] 67DIAMETER [2.6DIAMETER]
SPINDLE SPEED: MIN-1 MAX. 3000
SPINDLE MOTOR: KW[HP] 18.5/22 [25/30]
NUMBER OF TOOL STATIONS: 12+12
TURRET INDEX TIME: SEC 1.2
TURRET MECHANISM: TWO-PIECE COUPLING
CHUCK SIZE: INCH 10
SLIDE STROKE: X-AXIS MM[INCH] 265 [10.43]
Z-AXIS MM[INCH] 455 [17.91]
FEED MOTOR: X-AXIS KW[HP] 4.0 [5.4]
Z-AXIZ KW[HP] 4.0 [5.4]
ANW-4100 ROBOT SPECIFICATIONS:
ROBOT: L292-B1 OPTION : L292-J
CARRYING CAPACITY: KG [ LB. ] 10+10 [22+22] OPTION: 30 [66]
ROBOT CONTROLLER: MAX SP1
ANW-41000 MACHINE SIZE:
FOOTPRINT: MM X MM [ FEET, INCH X FEET, INCH ]
MACHINE HEIGHT: MM [ FEET, INCH ]
MACHINE WEIGHT KG [ LB. ]
MACHINE SPECIFICATIONS WITH LIVE TOOL:
ROTARY SPEED: MIN-1 5000
OUTPUT: KW[HP] 2.2/3.7 [3/5]
HOLDER SIZE: MM 1DIAMETER~20
NUMBER OF TOOL: 12

Equipped With:
ANW-4100 CNC CONTROL: FANUC 0I-TD

This machine is listed for sale by Machinery Resources International located in Simi Valley, California
