MAX SWING................. 16.5"
SWING OVER CROSS SLIDE.... 8.6"
DISTANCE BETWEEN CENTERS.. 40"
X-AXIS TRAVEL............. 8.6"
Z-AXIS TRAVEL............. 40"
CHUCK SIZE................ 10"
SPINDLE BORE.............. 1.97"
SPINDLE NOSE.............. A2-5
SPINDLE MOTOR............. 8 HP
SPINDLE SPEED............. 3,500 RPM
RAPID TRAVERSE RATE....... 250 IPM
APPROX MACHINE WEIGHT..... 4,000 LBS

EQUIPPED WITH:
BRIDGEPORT EZ PATH CONTROL
GEARED HEAD
(24) SPEEDS (37.5 - 3,500 RPM)
ELECTRONIC HAND WHEELS
DORIAN QUICK-CHANGE TOOL POST
TAIL STOCK
10" 3-JAW CHUCK
5C COLLET NOSE AIR CHUCK
SLIDE-OUT COOLANT PAN
WORK LIGHT
FLOPPY
RS232

** ORIGINAL OWNER
** MACHINE CUTTING PRIMARILY STEEL & ALUMINUM
** IN PLANT, UNDER POWER, READY FOR IMMEDIATE INSPECTION & PURCHASE

This machine is listed for sale by Clark Machinery Sales located in Hunt Valley, MD, Maryland
