SWING OVER BED.................. 36.22"
SWING OVER CROSS SLIDE.......... 27.55"
X-AXIS TRAVEL................... 14.56"
Z-AXIS TRAVEL................... 31.49"
C-AXIS INDEXING................. 0.001 DEG
CHUCK SIZE...................... 24"
BAR CAPACITY.................... 12.5"
SPINDLE NOSE.................... A2-20
SPINDLE MOTOR................... 50 HP
SPINDLE SPEED................... 1250 RPM
TURRET CAPACITY................. 12 STATIONS
TURRET TYPE..................... VDI
LIVE MILLING MOTOR.............. 7.5 HP

EQUIPPED WITH:
FANUC OiTC CNC CONTROL
24" SCA TYPE BS-610 4-JAW CHUCK ON FRONT
26" SCHUNK ROTA TB-630-310 3-JAW PNEUMATIC CHUCK ON REAR
FULL C-AXIS
TOOL PRESETTER
CHIP CONVEYOR
12 STATION VDI TURRET
AVAILABLE LIVE & STATIC TOOL HOLDERS

** MACHINE CAN BE SEEN UNDER POWER AND IS AVAILABLE FOR IMMEDIATE INSPECTION AND PURCHASE.

This machine is listed for sale by Clark Machinery Sales located in Hunt Valley, MD, Maryland
