SWING OVER BED.................. 31.75"
MAX CUTTING DIAMETER............ 16"
MAX CUTTING LENGTH.............. 23"
X-AXIS TRAVEL................... 12.5"
Y-AXIS TRAVEL........ ± 2.00 Inches
Z-AXIS TRAVEL........ 23"
CHUCK SIZE........... 10"
BAR CAPACITY......... 3"
SPINDLE BORE......... 3.5"
SPINDLE NOSE......... A2-6
SPINDLE MOTOR........ 30 hp
SPINDLE SPEED........ 4,800 RPM
RAPID TRAVERSE RATE - X-AXIS..... 945 in/min.
RAPID TRAVERSE RATE - Y-AXIS..... 500 in/min.
RAPID TRAVERSE RATE - Z-AXIS..... 1,200 in/min.
TURRET CAPACITY (STATIONS)....... 24
TURRET TYPE........... HYBRID BOT/VDI
LIVE MILLING.......... Yes
Y-AXIS................ Yes

EQUIPPED WITH:
C-AXIS
HIGH TORQUE LIVE TOOLING
PROGRAMMABLE HYDRAULIC TAILSTOCK
10" 3-JAW HYDRAULIC CHUCK
ROYAL ACCU-LENGTH 3-J COLLET CHUCK
HIGH-PRESSURE COOLANT SYSTEM (1,000 PSI)
AUXILIARY COOLANT FILTER SYSTEM
M19 SPINDLE ORIENTATION
SPINDLE LOAD MONITOR
SPINDLE DRIVE LINE ACCELERATOR
BELT-TYPE CHIP CONVEYOR
AUTOMATIC TOOL PRESETTER
VISUAL QUICK CODE
RIGID TAPPING
HIGH-INTENSITY LIGHTING
15" COLOR LCD MONITOR
MEMORY LOCK KEYSWITCH
USB

TOOLING INCLUDED:
(1) AXIAL DRIVEN ER-32 EPPINGER PRECIFLEX
(1) RADIAL DRIVEN ER-32 EPPINGER PRECIPLEX
(3) EPPINGER ER-32 PRECIFLEX STARTER KITS

** ORIGINAL OWNER
** MACHINE CUTTING PRIMARILY ALUMINUM
** MACHINE MANUFACTURED DATE: OCTOBER, 2011

** ALSO AVAILABLE IN SAME FACILITY: 2012 HAAS VF-10/50
** IN PLANT, UNDER POWER, READY FOR IMMEDIATE INSPECTION & PURCHASE

This machine is listed for sale by Clark Machinery Sales located in Hunt Valley, MD, Maryland
