14" BIRMINGHAM® Vertical Metal Cutting Band Saw
Bandsaws Vertical - Metal
CALL FOR AVAILABILITY AND BEST PRICING!
Saw blade butt welder with integrated annealing unit
Blade shear, grinder
Built-in blade and tire cleaning brush
Low voltage working lamp
One set of required tools
One instruction and parts manual
Throat Depth: 14" (355mm)
Max, work height: 9-1/16" (230mm)
Table Size: 19-1/2" x 15-1/4"
Table inclination (4 ways): 15"
Saw Blade Length: 111-13/16"
Saw Blade Width: 3-16mm
Saw Blade Speeds: 20-90m/min (65-295 fpm)
Butt Welder Capacity: 2.4 KVA 3-16mm (1/8" - 5/8")
Drive Motor: 1 HP
Net Weight (approx.): 551 lbs.
Gross Weight (approx.): 683 lbs.
Measurement (LxWxH): 37-3//16" x 22" x 72-13/16"
Rip Fence for straight, repeated cuttings easily removable for varied sizes
Miter protractor for angular cutting
Electro-magnetic switch and overload protection
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
