Photo: |
Machine Detail: |
Manufacturer: |
Price: |
| 26” x 26” Hyd-Mech Semi-Automatic Dual Post Horizontal Band Saw Model H-26 SPEICICATIONS:
90° Rectangle (H x W) 26” x 44”
90° Round 29”
90° Square 26”
Blade Drive 20 HP
Blade Speed 75-300 SFM
Blade S | HYD-MECH H-26 | $RFQ
Lake Bluff, IL United States |
| 36” Lapmaster Model SS36H Precision Pneumatic Flat Lapping Machine SPECIFICATIONS:
Lapping Plate 36” x 6.75 ID
Conditioning Rings (3) 16.5” OD x 14.5” D x 2.8”
Max. Distance Table to Hold Down Plates 9.8”
Table Dr | LAPMASTER SS36H | $RFQ
Lake Bluff, IL United States |
| 4.7” x 39” Ernest Fischer ZSM 1000 Center Hole Grinder SPECIFICATIONS:
Workpiece Capacity, Length Up to 39”
Diameter 0.2-4.7”
Grindable Center – Maximum 11.8”
Stroke (Automatic Grinding Motion) 0”-0 | Ernest-Fischer ZSM 1000 | $RFQ
Lake Bluff, IL United States |
| Haas Model VF4SS Vertical Machining Center SPECIFICATIONS:
X-Axis Travel 50” 762mm
Y-Axis Travel 20” 508mm
Z-Axis Travel 25” 635mm
Spindle Speed 12,000 RPM
Spindle Motor 40 HP Vector
Spin | HAAS VF4SS | $RFQ
Lake Bluff, IL United States |
| No. 6 Atlas Compound-Leverage Arbor Press SPECIFICATIONS:
Capacity 25 Ton
Ram Size 2-1/2” x 2-1/2” x 26”
Maximum Work Diameter 37”
Throat 18-1/2”
Maximum Distance from Ram to Top of Base | ATLAS No. 6 | $RFQ
Lake Bluff, IL United States |
| 10” x 18” Hardinge Model HLV-H Super Precision High Speed Tool Makers Lathe SPECIFICATIONS:
Spindle Capacity with Round 5C Collets 1-1/16”
Spindle Capacity with Hexagon 5C Collets 7/8”
Spindle Capacity with Square 5C Coll | HARDINGE HLV-H | $RFQ
Lake Bluff, IL United States |
| Henninger Model ZS201 Center Hole Grinder SPECIFICATIONS:
Largest Center Bore Diameter 90mm/3.54”
Smallest Center Bore Diameter 2mm/.078”
Dressing Angle Range 60°-90°
Grinding Wh | Henninger ZS201 | $RFQ
Lake Bluff, IL United States |
| Eitel Model RP-25 Straightening Press SPECIFICATIONS:
Maximum Straightening Pressure 27.5 Ton
Straightening Bed 54”L x 10.75”D x 14”H
Ram Speed Up 255 IPM
Ram Speed Down 115 IPM
Total | EITEL RP-25 | $RFQ
Lake Bluff, IL United States |
| Oberlin Model OPF-7 Automatic Pressure Filtration System SPECIFICATIONS:
Flow Rate (Water Based Coolant) 120 Gallons
Media Area (Accepts Standard Roll Media) 7 sq. ft.
Approximate Dimensions (Without Stai | OBERLIN OPF-7 | $RFQ
Lake Bluff, IL United States |
| 20 Ton Hansford Model 1020 Portable Die Handler SPECIFICATIONS:
Maximum Die Try-Out Force 20 Ton
Shut Height 8”
Open Height 28”
Travel of Upper Platen 20”
Platen Area Lower 24.5” x 44.5”
Manua | HANSFORD 1020 | $RFQ
Lake Bluff, IL United States |
| 16” x 32” Clausing (Chevalier) CLA1632 3 Axis Hydraulic Surface Grinder SPECIFICATIONS:
Table Size 15 ¾” x 31 ½” (400x800mm)
Max. Grinding Length (Longitudinal) 32” (810mm)
Max. Grinding Width (Crosswise) 16” | CLAUSING CLA1632 | $RFQ
Lake Bluff, IL United States |
| 3/4" X 15" Eldorado Mega Two Spindle M-75-1061 Precision Deep Hol 3/4" X 15" Eldorado Mega Two Spindle M-75-1061 Precision Deep Hole Gun Drill
SPECIFICATIONS:
Drilling Diameter Maximum .75 inches
Drill | ELDORADO-MEGA M-75-1061 | $RFQ
Lake Bluff, IL United States |
| 80 Gallon Crystal Clean Model AL80 Agitating Solvent Type Parts Wash Tank SPECIFICATIONS:
Platform Dimensions 17 ½” x 41 ½” x ½”
Tank Dimensions 27” x 44 ½” x 38”
Load Capacity 250 Lbs.
EQUIPPED WIT | Crystal-Clean AL80 | $RFQ
Lake Bluff, IL United States |
| HAAS Model SL10T CNC Turning Machine SPECIFICATIONS:
Bar Capacity 1.75”
Chuck Size 6”
Spindle Speed 6000 RPM
Spindle Motor 15HP
X-Axis Travel 7.9”
Z-Axis Travel 16”
Rapid Rate, Z-A | HAAS SL10T | $RFQ
Lake Bluff, IL United States |
| 19” x 78” Leblond-Makino Regal Servo-Shift Engine Lathe SPECIFICATIONS:
Swing Over Bed 19-1/4”
Swing Over Cross Slide 12-1/4”
Distance Between Centers 78”
Spindle Speeds (12) 40-1600 RPM
Hole Thru Spin | LEBLOND MAKINO 12E-511 | $RFQ
Lake Bluff, IL United States |
| 1” x 48” Technidrill/Triad Model G148 1.00.15-1CR Counter Rotating Deep 1” x 48” Technidrill/Triad Model G148 1.00.15-1CR Counter Rotating Deep Hole Drill
SPECIFICATIONS:
Drilling Depth, Max. 48” + 6” Clamp
Drilling D | TECHNIDRILL G148 1.00.15-1C | $RFQ
Lake Bluff, IL United States |
| Black Diamond Model BW-95PC Drill Grinder SPECIFICATIONS:
Range 1/16” – ¾”
Meter 1/3 HP, 1 PH, 115 Volt
Approximate Dimension (Including Base) 48” x 40” x 52” HT
Approximate Weight 17 | Balck-Diamond BW-95PC | $RFQ
Lake Bluff, IL United States |
| Brother TC-S2B CNC Drilling and Tapping Center SPECIFICATIONS:
Table Size 12” x 23.6”
Spindle Speed 10-10,000 RPM
Spindle Taper BT30
Spindle Nose to Table Top 6.3” – 16.9”
Spindle Motor 6.7” K | BROTHER TC-S2B | $RFQ
Lake Bluff, IL United States |
| 28-Ton Hannifin Schuler Model OGF-28 Hydraulic Gap Frame Press SPECIFICATIONS:
Maximum Tonnage 28 Tons
Bed Size 24” LR x 20.5” FB
Daylight 30”
Adjustable Stroke 25”
Throat Depth 20”
Cylinder Bore 6”
Ram Dia | Hannifin-Schuler OGF-28 | $RFQ
Lake Bluff, IL United States |
| 8,000 Lbs. (3700 kg) Hubtex Model MSU37 Electric Multidirectional Sideload 8,000 Lbs. (3700 kg) Hubtex Model MSU37 Electric Multidirectional Sideloader
SPECIFICATIONS:
Load Capacity @ 157” Height 8,140 Lbs.
Load Capacity | Hubtex MSU37 | $RFQ
Lake Bluff, IL United States |
| | | | | |
