17" SHARP® Radial Drill - $RFQ

Item Number: #00083577
17&quot; SHARP&#174; Radial Drill





17" SHARP® Radial Drill

Stock Code:  RD-2000
Price: $RFQ
Subcategory:

Radial Drills

Manufacturer:  Sharp
Model:  RD-2000
Condition: New

CALL FOR BEST PRICE!

FEATURES:
Sharp radial drills are excellent machines for tapping, drilling and boring large holes on cast iron or steel material. The traveling arm is made with hardened and ground slide ways for precise movement of head and spindle. The vertical column utilizes double tube design for rigidity. The spindle is equipped with depth setting.
The Sharp heavy duty Radial Drilling Machines are designed for a wide range of machining operations to be used under the most demanding conditions.
All major castings are made of closed grained full ribbed iron to give maximum stability under stress. The headstock gears are made of hardened and ground nickel-chrome alloy steel.
The arm is mounted with ground slideways and operated by electric control. It has a safety device that will prevent the arm from dropping due to unforseen reasons.
The rigidly ribbed casting base is provided with T-slots and drain channels. The spindle is designed for maximum speed, feed rate and depth.

STANDARD EQUIPMENT:
Box table
Coolant system
Work light
Toolbox

SPECIFICATIONS:
Diameter of column: 17"
Dist. column to spindle: 16.93"-78.74"
Travel of spindle head: 61.81"
Dist. Spindle to base: 15.34"-72.83"
Elevating height of arm: 43.31"
Effective area of table: 40" x 32" x 20"
Dimensions of base: 115" x 45" x 10"
Taper hole in spindle: MT# 5
Stoke of spindle: 14.57"
Spindle (rpm range x steps): 40-1920 x 12
Spindle feed (ipr x steps): 0.007"-0.96" x 6
Main motor (HP): 7.5 HP
Elevating motor (HP): 3 HP
Clamping Motor for Column & Gear Box: 1 HP
Clamping Motor for arm (HP): 1/2 HP
Coolant Pump: 1/8 HP
Machine height from floor, max: 136.61"
Measurement (LxWxH): 130" x 59" x 123.6"
Approx shipping weight (lbs): 15,620
Capacity Tapping Steel: 2"
Capacity Tapping Cast Iron: 2-3/8"

OPTIONAL ITEMS:
Tilting table

Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 1 YEAR – Parts
