45 Ton BAILEIGH® Horizontal Press Brake - $RFQ

Item Number: #00064627
45 Ton BAILEIGH&#174; Horizontal Press Brake





45 Ton BAILEIGH® Horizontal Press Brake

Stock Code:  HPB-45NC
Price: $RFQ
Subcategory:

Press Brakes

Tonnage45T
Manufacturer:  Baileigh
Model:  HPB-45NC
Condition: New

CALL FOR BEST PRICING!

FEATURES:
The HPB-45NC horizontal press brake form Baileigh Industrial is truly a must have in any fabrications shop. This do it all machine can bend, punch, and shear with the correct tooling, yet takes up very little space. The HPB-45NC makes it much easier to make smaller parts such as flanges and brackets, because the material has a surface to lie on during the process. No having to hold one side and hope that it is perfectly level or lined up; the perfectly machined table takes care of that for you.
The HPB-45NC runs on 220 volt three phase power and produces a whopping 45 tons of pressure with its 5 hp motor. Operation of the HPB-45NC is very simple. It comes standard with an NC controller that can handle up to 99 programs with up to 10 bends per program. The operator can also put the machine in a manual mode for one off projects and set up as well. Bends are actuated by foot pedal control so the operator's hands are free to assist with the material. The HPB-45NC has an accuracy of +/- .002”.
Other features included with the HPB-45NC horizontal press brake are a set of single-vee tooling (7.8" high) as well as a manual back gauge to help with repeatability. Many tooling set are also available to help with any project that you may have.
MADE IN TAIWAN

SPECIFICATIONS:
Pressure: 45 Tons
Stroke Length: 9.84"
Stroke Accuracy: +/- .002"
Approach Speed: 1.5"/Sec
Working Speed: .51"/Sec
Return Speed: .78"/Sec
Fixture Holes: 1 @ 3.268" Dia 3 @ 2.283" Dia
Punch Height: 7.875"
Max Bending Capacity: 7.875" (.472")
Table Height: 36.61"
Motor: 5 HP
Power Requirement: 220V/3 Phase
Shipping Dimensions (L/W/H): 64"/26"/47"
Shipping Weight: 2,266 lbs

OPTIONAL ITEMS:
Straightening Tool
Multi Vee Tooling
Flat Bar Bending Tool
Shearing Tool
Punching Tool
Multi Vee Bending Tool
Vee Tooling

Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 1 YEAR – Parts
