3-1/2" BAILEIGH® Tube & Pipe Bender with Touch Screen - $RFQ

Item Number: #00064831
3-1/2&quot; BAILEIGH&#174; Tube &amp; Pipe Bender with Touch Screen





3-1/2" BAILEIGH® Tube & Pipe Bender with Touch Screen

Stock Code:  RDB-350-TS
Price: $RFQ
Subcategory:

Benders - Pipe Tube & Bar

Manufacturer:  Baileigh
Model:  RDB-350-TS
Condition: New

Play YouTube Video
CALL FOR BEST PRICING!

FEATURES:
The true workhorse of the Baileigh Industrial line of tube benders is the RDB-350-TS. Designed and built in the USA to stand up to the rigors of production at any shop. This bender has the capacity to bend 2.5” schedule 40 pipe and up to 3” tube with a .187” wall thickness. As with all Baileigh Industrial tube benders, the RDB-350-TS accepts Baileigh Industrial's standard drop on tooling. And if you have a unique application, Baileigh Industrial can make just about any custom tooling that your application will call for. The RDB-350-TS also features one shot bending to 360° both left and right. 180° bends can be achieved in about 16 seconds. Quick release counter die system allows maximum efficiency because the pipe bender can be loaded and unloaded quickly for high production runs.

The RDB-350-TS has a user friendly touch-screen controller that allows the user to store up to 170 programs within the memory of the controller itself and unlimited program storage/backup via micro SD port, with up to 10 bends per program. The RDB-350-TS can be programmed for desired angle, spring back for the material, and speed of the bend. Rotational orientation can also be kept track of within the programmer. Another unique feature of this pipe bender is the 320° rotation of the controllers head. This feature allows the RDB-350-TS to be operated from any location around the machine.

Like all Baileigh computer controlled tube and pipe benders, the RDB-350-TS can accept a rotary positioning table. This table is available in various lengths for repeatable bends in a single piece of material. When the table is attached to the tube bender, it helps achieve very accurate bends in varying planes, as well as consistent measurements between bends.
MADE IN UNITED STATES

SPECIFICATIONS:
Mild Steel Pipe (Schedule 40): 2.5"
Aluminum Pipe (Schedule 40): 3"
Stainless Steel Pipe (Schedule 40): 2"
Mild Steel Round Tube (Wall): 3" (.187)
Aluminum Round Tube (Wall): 3.5" (.250)
Stainless Steel Round Tube (Wall): 3" (.125)
Chromolly Round Tube (Wall): 2.5" (.125)
Mild Steel Solid Rod: 1.5"
Mild Steel Square Tube (Wall): 3" (.125)
Minimum OD: .25"
Maximum Speed to 180 Degrees: 16 Seconds
Maximum Center Line Radius (CLR): 24"
Minimum CLR: .5"
Power Requirements: 220V (3-Phase)
Dimension (L x W x H): 69" x 32" x 46"
Weight (Lbs.): 1,500

OPTIONAL ITEMS:
B-LUBECP: Biodegradable Bend Lube: 8oz
B-LUBEPT: Biodegradable Bend Lubes: 16 oz
B-LUBEQT: Biodegradable Bend Lubes: 32 oz
ORG-3600: Outside Radius Gauge
IRG-3600: Inside Radius Gauge
AF-360D: 360 Degree Digital Angle Finder
AF-360D-Holder: Clamp and Holder for AF-360D Angle Finder
RT-1B: Round Tube Die Package
RT-2B: Round Tube Die Package
RT-3B: Round Tube Die Package
RT-4B: Round Tube Die Package
RT-5B: Round Tube Die Package
RP-1B: Round Pipe Die Package
RP-2B: Round Pipe Die Package
RP-3B: Round Pipe Die Package
ST-1B: Square Tube Die Package
ST-2B: Square Tube Die Package
UBP-1200-325: Bend Plate for RDB-325
BT-PRO: Bend Tech - Tube and Pipe Bending Layout Software: Bend Tech Pro
BT-SE: Bend Tech - Tube and Pipe Bending Layout Software: Bend Tech SE
10' Index Table for RDB-325: IDX-10-325
10' Index Table for RDB-325 w/4-Jaw Chuck: IDX-10-CMH-4-325
15' Index Table for RDB-325: IDX-15-325
15' Index Table for RDB-325 w/4-Jaw Chuck: IDX-15-CMH-4-325
20 Index Table for RDB-325: IDX-20-325
20 Index Table for RDB-325 w/4-Jaw Chuck: IDX-20-CMH-4-325
Indexing table can be fitted allowing the fabricator to bend on varying planes and easily duplicate complex bends.
Rotary positioning table available in various table lengths for repeatable bends in a single piece of material. Allows this bending machine to have accurate bends in varying planes, as well as consistent measurements between bends.


Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 1 YEAR – Parts
