Machine Tools > Saws > Bandsaws Vertical - Metal    < Back

8.75" Throat 14.5" Height Roll-In EF1459 *Made in the USA* BAND SAW, Handles all metals, plastics, and woods; 1 or 3 ph - $4,795

Item Number: #00019344
8.75&quot; Throat 14.5&quot; Height Roll-In EF1459 *Made in the USA* BAND SAW, Handles all metals, plastics, and woods; 1 or 3 ph





8.75" Throat 14.5" Height Roll-In EF1459 *Made in the USA* BAND SAW, Handles all metals, plastics, and woods; 1 or 3 ph

Stock Code:  139146
Price: $4,795
Subcategory:

Bandsaws Vertical - Metal

Throat capacity8.75"
Height capacity14.5"
Manufacturer:  Roll-In
Model:  EF1459 *MADE IN THE USA*
Condition: New

NEW ROLL-IN VERTICAL BAND SAW MODEL EF1459


Cuts Metals, Plastics, and Woods Safely and Efficiently





*Made in the USA*





Roll-In Saw built its reputation on the versatility and durability of this terrific band saw – the EF1459, a.k.a, "The Original."  This was the first saw in America to use a patented gravity-feed system that saves time and energy.





The EF1459 is actually a horizontal band saw on a vertical frame.  An all-purpose band saw, it handles all metals, plastics, and woods in a wide variety of cuts.  It is a fast, accurate cut-off machine that is perfect for notching, slitting, and slotting.  A reliable addition to your shop floor, this band saw doubles as a contour, profile, and rip saw.





Accurate Gravity Feed


The EF1459 band saw has a capacity of 14-1/2 inches under the guides and a 9 inch cut.  The blade and vertical column travel on an inclined track that feeds into the cut in a straight path.  Gravity enables the blade to find its most efficient feed rate.  Counterweight control provides adjustment for optimum cutting pressure and long blade life.  The work piece remains stationary and your hands need not be in the cutting area during cut-off, an important safety feature.





Hydraulic Feed Control and Blade Shield


The Roll-In Saw Vertical EF1459 is equipped with a hydraulic safety feed regulator and adjustable saw blade guard.  An adjustable stop can be pre-set to control the depth that the blade travels into the work.





High Quality, Yet Cost-Effective


The Roll-In Saw EF1459 is equipped with a large, rigid 18-1/2 inch x 30 inch precision-ground table. Hardened grooved roller guides allow blades from 1/4 to 3/4 inch wide without adjustment.  Blade wheels have rubber tires to prevent blade slippage.  The band saw comes furnished with an angle plate swivel work block, large C-clamp, blade/speed selector chart, blade, one horsepower motor and switch.  It is available in either 110V or 220V single-phase, or 220V or 440V three-phase options.





SPECIFICATIONS:


Capacity Under Guides ............................... 14-1/2"


Throat .............................................. 8-3/4"


Blade Travel ........................................ 9" Blade travel into work


Blade Size .......................................... 3/4" Width x 8/12T x 10' Length .035 thick (bi-metal)


Guards .............................................. Covers 4 step pulleys, blade and lower wheel


Guide Rollers for Blade Width ....................... 1/4", 3/8", 1/2", 5/8" and 3/4"


Blade Speeds ........................................ 70, 140, 270 and 525 fpm


Table ............................................... Precision ground, cast iron table, 18-1/2" x 30"


Table Height ........................................ 30" from floor


Wheels .............................................. Cast iron, 14" x 1 1/8"


Wheel Tires ......................................... Replaceable rubber


Motor ............................................... 1 HP, 110/220V, 60-cycle single-phase;


                                                      1 HP 220/440V, 60-cycle three-phase


Dimensions .......................................... 30" Width x 66" Height x 40" Length


Shipping Weight ..................................... 650 lbs. F.O.B Cleveland, Ohio





OPTIONAL EQUIPMENT (CALL FOR PRICING):


1" Guide Rollers


Casters 4 Per Set


Chip Dust Blower


Contour Guide Assembly


Saw Master® Accessory Package


Factory Installed Work Light


1" Welder, Grinder and Shear/Bench Model
